GENERAL DATA OF T10 VALVESValve function 3/2N.C. 3/2N.O.2/2N.C.2/2N.O.Media Compressed air Inert gasesLubricationNot necessaryAmbient and media temperature-10℃~+50℃Working pressure0~7barOrifice size ¢0.75mm(P port) /¢1.0mm(R port)flow value at 4 bar(direct emptying test)18L/min(1→2) , 28L/min(2→3)COIL DATA OF T10 VALVESElectrical connection Vertical type(Ltype)Horizontal type(M type)Direct line type(G type)Nominal voltageAC220V、DC24V、DC12V、DC6V、DC5V、DC3V Voltage tolerance±10%Duty cycle ED100%Insulation classH Degree of pretectionIP50 Response timeLess than 10ms Lifetime expectancyMore than 30 millon times
GENERAL DATA OF T10 VALVESValve function3/2N.C.3/2N.O.2/2N.C. 2/2N.O.MediaCompressed air Inert gasesLubricationNot necessaryAmbient and media temperature-10℃~+50℃ Working pressure0~7barOrifice size ¢1.0mm(P port) /¢1.2mm(R port)flow value at 4 bar(direct emptying test)28L/min(1→2) , 35L/min(2→3)COIL DATA OF T10 VALVESNominal voltage Vertical type(Ltype)Horizontal type(M type)Direct line type(G type)Nominal voltageDC24V、DC12VVoltage tolerance±10%Duty cycle ED100%Insulation classHDegree of pretectionIP50Response timeLess than 10msLifetime expectancyMore than 30 millon times
